Excellence in High-Speed, High-Density, and Reliability Since 2007.
In today’s fast-paced electronics industry, superior product performance begins with precision PCB Layout Design. It is not merely the physical realization of a schematic; it is the core determinant of Signal Integrity (SI), Power Stability, EMC Compliance, and ultimate product reliability.
Since its establishment in 2007, DuxPCB has mastered this discipline. Our professional PCB Layout services are the critical step in transforming your innovative concepts into market-leading products.
Our Commitment: To build excellence with "Tier-1 Manufacturing" standards. Whether you are a startup seeking a breakthrough or a mature brand pursuing peak performance, DuxPCB’s design team ensures your PCB design is flawless with industry-leading technology and rigor.
We are not just designers; we are your trusted engineering partners. Partnering with DuxPCB grants you access to:
Since diving into electronics manufacturing in 2007, DuxPCB has accumulated massive practical experience in PCB Layout. We have successfully delivered thousands of projects covering high-end sectors such as Consumer Electronics, Industrial Control, Medical Devices, IoT, and Telecommunications.
High-Speed PCB Design: Expertise in DDRx, PCIe, Ethernet, USB 3.0, and impedance matching.
HDI (High Density Interconnect): Mastery of Blind/Buried vias and Micro-via technology for miniaturization and high integration.
Multi-Layer Design: From standard 2-layer boards to complex 30+ layer high-end designs, specializing in stack-up planning and SI optimization.
PI & SI Analysis: Pre-layout simulation to mitigate risks and ensure system stability.
EMC/EMI Optimization: Suppressing interference at the source to improve immunity and compliance.
DuxPCB boasts a team of seasoned electronics engineers and dedicated Layout specialists.
Tool Mastery: Proficient in top-tier EDA tools including Cadence Allegro, Altium Designer, and Mentor PADS.
Theoretical Depth: Our team possesses deep circuit theory knowledge and strict adherence to IPC standards.
** rigorous Management:** We follow a strict project management process, verifying every step from requirements analysis to final delivery to ensure impeccable design quality.
As a One-Stop OEM, our design philosophy is centered on Design for Manufacturing (DFM) and Design for Assembly (DFA).
Integrated Engineering: Our layout engineers collaborate closely with our manufacturing, sourcing, and assembly teams from the design phase.
Result: We ensure every design can be produced efficiently, at low cost, and with high yield. This shortens your time-to-market and significantly reduces overall production costs.
Our Layout Service is a critical link in the DuxPCB "PCB Fab + Sourcing + SMT Assembly + Box Build" turnkey solution.
Direct Translation: Your design is directly converted into high-quality PCBs and PCBA finished products within DuxPCB. This eliminates multi-party communication gaps and data conversion errors, drastically improving project efficiency and success rates.
DuxPCB follows a transparent, standardized process to ensure smooth project execution:
Requirements Analysis: Deep dive into your project needs, specs, performance metrics, and cost targets.
Schematic Review: Professional audit of your schematic with optimization suggestions to ensure logic validity.
Stack-up Planning: Designing the optimal layer stack-up based on signal types, power distribution, and EMC requirements.
Library Management: Building or importing high-precision, standard-compliant component footprints.
Placement (Floorplanning): Strategic component layout based on the schematic, mechanical constraints, and signal flow.
Routing: Strict adherence to SI/PI and EMC rules for routing, including differential pairs, length matching, and impedance control.
Verification (DRC/LVS): Conducting Design Rule Checks (DRC), Layout vs. Schematic (LVS) checks, and electrical validation.
DFM/DFA Audit: Final manufacturability and assembly review by our manufacturing expert team.
Deliverables Output: Delivery of the complete design package (Gerber, ODB++, Assembly Drawings, Stencil Files).
Tier-1 Strength: Industry-leading technical capabilities, a senior team, and rigorous processes ensuring world-class design quality.
Proven Track Record: Years of successful case studies serve as the best proof of our professional capabilities.
Hassle-Free One-Stop: From design to manufacturing, DuxPCB provides a full-chain service to save you time and effort.
Customized Solutions: Tailored design proposals based on a deep understanding of your unique requirements.
Let your product lead the market from the starting line!
DuxPCB is committed to being your most trusted electronics manufacturing partner. Regardless of your project's scale or complexity, we are ready to provide high-quality PCB Layout services with professional attitude and technical excellence.
