Product Description
Overview of Impedance Controlled PCB

In the realm of high-speed digital design and Advanced PCBA Solutions, the Impedance Controlled PCB serves as the foundational architecture for maintaining Signal Integrity. At DuxPCB, we specialize in High-Density Interconnect (HDI) boards where precise Controlled Impedance is non-negotiable. Utilizing Any-layer HDI technology and Stacked Vias, our boards support Fine Pitch BGA components and high-frequency RF applications. We adhere to IPC-6012 Class 3 standards, ensuring that every trace geometry is optimized to prevent signal reflection and electromagnetic interference. Our manufacturing process integrates Laser Microvias and advanced Thermal Management strategies to deliver reliability in the most demanding AI Server and military-grade environments.

Technical Capability Table
Impedance Tolerances ±5%
Layer Count 1-36L
Maximum Copper Thickness 18oz
Minimum Trace Width and Spacing 2.5mil
Minimum Via Size for Laser 0.1mm
Minimum Via Size for Machine 0.15mm / 6mil
Base Material FR-4, High Tg FR-4, Aluminum, Rogers, etc
Board Thickness 0.2-8mm
Thickness Tolerance ≤1.0mm: +/-0.10mm, >1.0mm:+/-10%
PCBA Services SMD, SMT, DIP Component Assembly
Surface Finish LF HASL, plating hard gold, ENIG, ENEPIG, Immersion Tin, Immersion silver, OSP
Certifications ISO9001, ISO14001, CE, RoHS, UL, IATF16949, ISO13485
Why Partner with DuxPCB?
  • 1. Overcoming Yield-Killing Complexity: Most manufacturers struggle when layer counts exceed 20 or trace widths drop below 3mil, leading to catastrophic yield losses. DuxPCB thrives on these high-difficulty builds, utilizing advanced registration systems to ensure that complex Any-layer HDI designs are manufactured with repeatable precision.
  • 2. Eliminating Field Failures in High-Reliability Sectors: For AI Servers and Military applications, a single signal deviation can result in system-wide failure. We mitigate this risk by enforcing IPC-6012 Class 3 rigor, ensuring that our Impedance Controlled PCB maintains absolute Signal Integrity under the highest data rates.
  • 3. Advanced Material Stability: Delamination and signal loss are common fears when mixing exotic materials like Rogers with High-Tg FR4. Our deep material expertise ensures perfect thermal expansion matching, preventing structural failures in harsh environments through superior Thermal Management.
  • 4. Engineering as an Extension of Your Team: We stop design errors before they reach the factory floor. Our front-end DFM (Design for Manufacturing) engineering support acts as your internal QA, identifying bottlenecks in Fine Pitch BGA layouts and via-in-pad structures to guarantee a seamless transition from prototype to mass production.
Technical FAQs

Q: How do you guarantee an impedance tolerance of ±5%?
A: We utilize advanced TDR (Time Domain Reflectometry) testing and precise etching compensation software to maintain trace consistency across the entire production panel, ensuring even the most sensitive differential pairs meet specifications.

Q: Can DuxPCB handle hybrid stackups involving Rogers and FR-4?
A: Yes. We specialize in high-difficulty hybrid lamination processes, optimizing the bond strength and thermal profiles to prevent delamination during lead-free soldering processes.

Q: What is the benefit of using Laser Microvias in impedance-controlled designs?
A: Laser Microvias allow for much smaller aspect ratios and reduced parasitic capacitance compared to mechanical drilling, which is critical for maintaining signal path purity in High-Density Interconnect (HDI) applications.

Q: Do you support IPC-6012 Class 3 for medical or aerospace projects?
A: Absolutely. Our facility is certified for ISO13485 and IATF16949, and we provide full cross-sectioning and micro-section analysis to verify compliance with Class 3 reliability standards.

Ready to move beyond standard manufacturing limitations? Upload your Gerber files today for a comprehensive technical review by our engineering team, or contact our specialists to discuss your high-speed Signal Integrity requirements. Experience the DuxPCB advantage in high-difficulty execution.
